A small boat has a small console, a small battery and usually a small budget — and yet it goes into exactly the water where a chartplotter earns its keep: shallow bays, rocky inlets, tidal creeks and river mouths where the depth changes faster than your eyes can follow. The wrong unit is too big to mount, too hungry for a single battery, or so fiddly that you stop looking at it. The right one becomes the thing you glance at more often than the compass.

This guide covers seven chartplotters that work on boats from a 12 ft kayak or jon boat up to a 25 ft cuddy cabin. Every one of them combines GPS charts with sonar, runs happily on a 12 V battery and fits a 7-inch (or smaller) mounting footprint. If you want sonar without charts, see our best GPS fish finders guide instead.

Quick pick: if you just want the answer

For most small boats: the Garmin ECHOMAP UHD2 73sv (7-inch). The clearest screen in the class, strong preloaded coastal or inland charts depending on your region, side- and down-scanning sonar through the included transducer, and a keypad you can work with wet hands or gloves. It is the unit we would put on a 16–22 ft boat without hesitation.

If you fish more than you navigate: the Lowrance Elite FS 7. The best sonar imaging at the price, and a touchscreen fast enough to be a pleasure rather than a chore.

If money is tight: the Lowrance HOOK Reveal 7 or the Garmin ECHOMAP UHD2 53cv. Real charts, real sonar, roughly half the price.

 Garmin ECHOMAP UHD2 73sv with GT54UHD-TM transducer

What “small boat” changes about the decision

Big-boat reviews talk about networking, radar overlays, and 16-inch multifunction displays. None of that matters on a small boat. Six things do.

Screen size versus mounting space. A 7-inch unit is the sweet spot: readable at arm’s length in sunlight, yet small enough to sit on a bracket at the helm or on a rail. Nine-inch units are lovely but often block the view or the throttle on a small console. Five-inch units suit kayaks and jon boats but are hard to read at speed.

Power draw. A small boat often has one battery that also starts the engine. A 7-inch unit with sonar draws around 1–1.5 A; a 9-inch unit with a large transducer can draw twice that. Over a day of drifting and fishing, the difference decides whether the engine starts on the way home.

Transducer mounting. Most small boats use a transom-mount transducer, and every unit below ships with one. If you have a kayak or an inflatable, check for in-hull or trolling-motor mounting options before you buy.

Buttons versus touchscreen. Touchscreens are quicker in calm water and useless with wet, cold hands in chop. On a small open boat, a keypad or a hybrid (touch plus buttons) is usually the better call. Buying touch-only and regretting it is the single most common complaint we hear from small-boat owners.

Charts. A unit is only as good as its cartography. Garmin ships Navionics+ or BlueChart g3 (region-specific), Lowrance ships C-MAP, Raymarine ships LightHouse charts, and Humminbird ships its own basemap with optional upgrades. For coastal use, check that the bundle you buy actually covers your area: the same model number can ship with US inland, US coastal, or “worldwide basemap” charts, and the difference is significant.

Weather sealing. Look for IPX7 (immersion) rather than IPX6 (spray). Small boats get wet.

The picks

1. Garmin ECHOMAP UHD2 73sv — best overall for small boats

A 7-inch keypad unit with a very bright, high-contrast screen and Garmin’s UHD ClearVü and SideVü scanning sonar, using the GT54UHD-TM transducer in the box. The chart engine is the smoothest in this class, route planning takes seconds, and it pairs with the ActiveCaptain app so you can plan a route on your phone and push it to the unit. Preloaded charts vary by region (Navionics+ inland or coastal in the US), so check the bundle carefully. The quick-release bail mount is a small detail that matters on an open boat: with one lever, the unit comes off for the night.

Weak points: keypad only, no touch — some prefer it, some don’t; the sv transducer is large for a kayak.

 Garmin ECHOMAP UHD2 73sv]

2. Lowrance Elite FS 7 — best for anglers

Lowrance’s mid-range touchscreen with Active Imaging 3-in-1 sonar (CHIRP, SideScan and DownScan), preloaded C-MAP Contour+ charts and, importantly, the option to add ActiveTarget live sonar later. The touchscreen is responsive, and the interface is the easiest to learn of the seven. This is the unit for someone whose small boat is first and foremost a fishing platform and who navigates to reach the fish.

Weak points: touch only, so awkward when wet; a little more power-hungry than the Garmin.

→ [AMAZON-LINK: Lowrance Elite FS 7 with Active Imaging 3-in-1]

3. Garmin ECHOMAP UHD2 53cv — best compact/budget Garmin

A 5-inch keypad unit with CHIRP and ClearVü down-scanning sonar and the same chart engine as the 73sv, in a footprint that fits a kayak, a canoe, a jon boat, or the smallest RIB console. Easily readable in sunlight, light on power, and cheap enough to buy alongside the boat. If you are torn between this and a 7-inch, the honest answer is “get the 7-inch if it fits” — but when it doesn’t, this is the one.

Weak points: no side-scanning; a 5-inch chart is cramped once you zoom out to plan a passage.

→ [AMAZON-LINK: Garmin ECHOMAP UHD2 53cv]

4. Lowrance HOOK Reveal 7 — best value with real charts {#lowrance-hook-reveal-7}

The HOOK Reveal is Lowrance’s entry line, and the 7-inch version with the TripleShot transducer (CHIRP, SideScan and DownScan) and C-MAP Contour+ charts is one of the best-value chartplotters ever made for small boats. Autotuning sonar means you rarely touch the settings, and FishReveal overlays fish arches onto DownScan, which beginners love. For an under-20 ft boat used for weekend fishing, it is often the sensible buy.

Weak points: the screen is a step behind the Elite FS; it cannot be networked or expanded later.

→ [AMAZON-LINK: Lowrance HOOK Reveal 7 TripleShot]

5. Raymarine Element 7 HV — best sonar detail per dollar {#raymarine-element-7-hv}

Raymarine’s Element is a keypad-driven 7-inch unit with HyperVision sonar — 1.2 MHz CHIRP— that delivers extraordinarily sharp structure imaging in shallow water, exactly where small boats live. LightHouse charts are included (region-dependent), and the screen is very bright. The interface is more “marine electronics” and less “smartphone” than Lowrance’s, but for structure hunting in under 30 ft of water, nothing at this price beats it.

Weak points: the HV transducer is bulky; the unit runs a little warm; the menus take a weekend to learn.

→ [AMAZON-LINK: Raymarine Element 7 HV with HV-100 transducer]

6. Humminbird HELIX 7 CHIRP MSI GPS G4N — best for Minn Kota owners {#humminbird-helix-7-msi-g4n}

If your small boat has a Minn Kota trolling motor, the HELIX 7 talks to it: spot-lock, follow-the-contour, and routes driven straight from the plotter. MEGA Side Imaging and Down Imaging are excellent, the keypad is glove-friendly, and Humminbird’s basemap plus optional LakeMaster or CoastMaster charts are strong in US inland waters.

Weak points: less compelling outside North America and for pure coastal navigation; the value case depends on owning the trolling motor.

→ [AMAZON-LINK: Humminbird HELIX 7 CHIRP MSI GPS G4N]

7. Simrad Cruise 7 — best for navigation-first boaters {#simrad-cruise-7}

The Cruise line is Simrad’s simplified chartplotter for people who want to get from A to B safely rather than hunt structure. A rotary knob and three buttons control the entire interface; charts are preloaded (C-MAP, region-dependent), and the sonar is basic CHIRP via a transom transducer. It is the right unit for a small cruiser or a sailing dinghy owner who never fishes, and its low power draw suits a boat without an alternator.

Weak points: basic sonar with no scanning imaging; no touchscreen and no upgrade path if you take up fishing later.

→ [AMAZON-LINK: Simrad Cruise 7]

Comparison table {#comparison}

Add a “Check price” column via AAWP/Lasso with [AMAZON-LINK] per row.

Mounting and powering a chartplotter on a small boat {#mounting}

https://amzn.to/4cJvMwsBuying the unit is half the job. On a small boat, the mount, the wiring, and the transducer position decide whether you actually use it.

Mounts. All seven come with a bail (bracket) mount. For a rail, a tiller boat, or a kayak, a RAM ball mount or a dedicated kayak track mount is the most common upgrade: it lets you angle the screen toward the helm and remove it in seconds.

→ [AMAZON-LINK: RAM Mount for 7-inch chartplotter]

Power. Wire the unit to the battery through an inline fuse (usually 3 A; check the manual) rather than through the accessory socket. If the boat has no battery — kayaks, canoes, some dinghies — a small 12 V lithium (LiFePO4) battery with 10–20 Ah capacity can run a 7-inch unit all day.

→ [AMAZON-LINK: 12V 12Ah LiFePO4 fish finder battery]

Transducer placement. A transom-mount transducer must sit in clean water flow, clear of the outboard’s turbulence, with its bottom flush with the hull. A poorly placed transducer produces a noisy sonar screen at speed and is the reason most owners decide their new unit “doesn’t work”. Ten minutes with the manual’s placement diagram saves a season of frustration.

Cover. A sun cover extends the screen’s life and hides the unit at the dock. Most units ship without one.

→ [AMAZON-LINK: Sun cover for Garmin ECHOMAP UHD2 7-inch]

Chartplotter or just a phone app?

A fair question on a small boat. Navionics and similar apps on a phone are excellent for planning and passable for navigation in calm conditions. What they cannot do is show sonar, survive a day of sun and spray, stay visible in bright light, or keep running once the phone battery dies. For a boat used during the day on a familiar lake, an app in a waterproof case may be enough. For coastal water, tides, and any kind of fishing, a dedicated unit pays for itself the first time it shows you a rock the phone did not. Our guide to using GPS to track tides and currents covers what a real plotter adds.

Common questions

Which chartplotter is best for a kayak? The Garmin ECHOMAP UHD2 53cv: a 5-inch footprint, low power draw, and a transducer that mounts in a scupper or on a track arm. Pair it with a 10 Ah lithium battery and a track mount. A 7-inch unit works on wider fishing kayaks with a proper console.

Which chartplotter is best for a RIB? A keypad unit, because RIBs are wet and bouncy. The Garmin ECHOMAP UHD2 73sv is our first choice; the Raymarine Element 7 HV is the alternative if the RIB doubles as a fishing boat.

Do I need a chartplotter and a fish finder, or does one unit do both? Every unit in this guide does both. A “chartplotter fishfinder combo” is simply a chartplotter with sonar built in and a transducer in the box, which is what small-boat owners almost always want.

Is a 7-inch chartplotter big enough? For any boat under 25 ft, yes. It is readable at arm’s length in sunlight and still fits a small console. Go to 9 inches only if you have console space and a matching battery.

Can I run a chartplotter without a boat battery? Yes. A 12 V LiFePO4 battery of 10–20 Ah runs a 7-inch unit with sonar for a full day and weighs less than a bag of ice.

Verdict

Get the Garmin ECHOMAP UHD2 73sv if you want one unit that does everything well and fits almost any small boat. Choose the Lowrance Elite FS 7 if fishing comes first, the HOOK Reveal 7 or UHD2 53cv if the budget or the console is small, and the Raymarine Element 7 HV if you spend your time hunting structure in shallow water. Whichever you buy, spend the leftover money on a proper mount and a sun cover: they are what make a chartplotter part of the boat rather than a gadget in a locker.

→ [AMAZON-LINK: Garmin ECHOMAP UHD2 73sv — our top pick]

---
